Turbo Electromotor with Straight Shaft Metal Cover (2114)

In the competitive home appliance market, your brand reputation is tied to the flawless and durable performance of your products. The end consumer may not recognize the complex technical differences, but he will never forget the excessive noise, poor suction or premature failure of the kitchen hood. The beating heart of the hood, the electromotor, is the ultimate determinant of customer satisfaction and your after-sales service costs.

The Turbo Electromotor with Straight Shaft Metal Cover (Model 2114) from the flagship product series of Electro Nasa (Arvin Industries) is a decisive answer to these challenges. This product is not an ordinary part, but an engineered solution for manufacturers who are looking for the highest level of durability (thanks to the metal cover), powerful turbo suction and absolute peace of mind with an unconditional 30-month warranty.

At Arvin Industries, as the first specialized manufacturer of hood electric motors in Iran, we have designed a model that directly targets the durability and efficiency of your final product and helps you to market a premium and reliable product.

Place an order and inquire about the price of Turbo Electric Motor (2114)

To receive specialized technical advice, receive a product sample for R&D tests, inquire about wholesale prices (B2B), or place an order directly from the factory, contact Arvin Industries Sales Department on WhatsApp.

Receive an online pre-invoice and register a purchase request

Key technical specifications table (2114)
Specification Value
Product name: Single-shaft turbo electric motor with metal cover
Product code: 2114 / 2114M
Manufacturer: Namavaran Industries Arvin Company (Electro Nasa brand)
Coil type: 100% pure copper
Stator thickness: 30 mm (customizable)
Cover material: metal (spiral) with electrostatic paint coating
Improvement type: plastic impeller (Bakelite) – Turbo Forward
Output air exchanger diameter: 100 mm (standard)
Number of speeds: 3 speeds
Thermal class: Class B
Maximum working environment temperature: 45 degrees Celsius
Warranty: 30 months unconditional replacement warranty
Warranty: 5 years after-sales service (parts supply)
Technical specifications analysis: Why are these numbers important when purchasing a single-shaft turbo electric motor with metal cover (2114)?

The above table goes beyond a few simple numbers. The 30 mm stator thickness, along with the 100% copper winding (and not copper-clad aluminum), guarantees strong starting torque and high efficiency, which directly translates into higher suction power (m³/h). More importantly, the metal cover is the main distinguishing feature of this model, making it completely resistant to the constant heat of the stove and preventing any deformation or deformation in the long term (unlike some plastic models).

Why is the metal cover model (2114) a strategic choice for your production line?

Every component you use in your final product is a result of costs and benefits. The 2114 electromotor is a strategic investment in your brand reputation.

۱. Buy a single-shaft turbo motor with a metal cover (2114) Unrivaled durability against heat with an “all-metal cover”

The biggest weakness of hood motors is constant exposure to heat from cooking.

Problem: Common plastic covers, even fireproof ones, are prone to deformation (change of shape) and brittleness after months and years of exposure to grease and heat. This slight deformation disrupts the balance of the impeller and leads to a sharp increase in noise and vibration.
Solution for model 2114: In this model, we have used an all-metal cover with a heat-resistant electrostatic paint coating. This metal structure maintains its dimensional stability under any temperature conditions. This means maintaining the balance of the impeller, maintaining the sound level (NVH) and a much longer useful life for your final product. This difference will be your trump card in the market to prove the durability of your product.

۲. Powerful Suction with Turbo Forward Design

Consumers expect strong suction from their hoods.

Engineering: The Turbo impeller design with forward-curved blades is engineered using computational fluid dynamics (CFD) principles to create maximum airflow against high static pressure (resistance from filters and exhaust duct length).

The result: This motor forces air through the filters with power, ensuring that your hood performs beyond expectations, whether in internal filtration or exhaust mode.

۳. Flexibility of the Turbo Electric Motor with Metal Cover Shaft (2114) in Product Design with 3 Speeds

This motor is available in 3 speeds (adjustable to 2 speeds based on your needs).

Advantage for the designer: This feature allows you to define different operating modes for your hood:
Speed ​​۱ (Low): Very quiet operation (Low Noise) for continuous and light ventilation.
Speed ​​۲ (Medium): Standard mode for daily cooking.
Speed ​​۳ (Turbo/Boost): Maximum suction power for heavy frying or when you need to quickly evacuate odors.
This flexibility allows you to cover several hood models (Economy, Standard, Premium) with a single motor.

۴. Reducing assembly time and errors in the production line of the turbo direct drive electric motor with metal cover shaft (2114)

We understand how valuable time is in the production line.

Standardization: The turbo direct drive electric motor with metal cover shaft model 2114 with a standard 100 mm air outlet and standard mounting points is easily compatible with most hood bodies available in the Iranian market.
Ease: This high adaptability means less need for changes in body molds, faster assembly process and less human error on the production line.

Why Arvin Industries (Electro Nasa)? More than a supplier, a strategic partner

When you choose the beating heart of your product, only you
